What Type of Electronic Meters Work With Solar Power Systems? Everything You Need To Know.

Solar panels are not the only component of a Solar Power Systems. They’re the show-stealer, generating electricity from the sun that is both emission- and cost-free. However, without other components like inverters, distribution panels, and meters, they would be unable to provide you with free electricity.

You might be wondering – What’s a solar Meter? Why is it important? Let’s understand.

What are Solar Power Meters?

Meters for solar power systems can be pyranometers, which measure solar radiation flux density (W/m2), or devices that measure the kWh generated by a PV system. The latter is the subject of this article.

To monitor and analyze PV plant performance, solar meters collect PV yield production and local energy consumption. Solar meters frequently include a monitoring feature that alerts plant owners to problems with PV plant performance, allowing them to quickly resolve problems and maximize return on investment.

How do solar meters work –

When your solar power systems produces more electricity than you consume during the day; the excess is send back to the grid; effectively running your electric meter backward. You can produce enough electricity to match your home’s electricity use for the entire year with the right size solar energy system.

Advantages of having Solar Electronic Meter-

• Reduced electricity bills are one of the benefits of using an electronic meter.
• Environmentally friendly.
• There’s no need to invest in a costly battery storage system.
• Reduce the strain on electric grids.
• Encourages customers to switch to renewable energy sources.
• Natural energy resources is preserve.

What Types of Electricity Meters is Use in Solar Panel Systems?

Despite whether or not a solar PV systems is installed, each household has a power meter that records the consumption per house or apartment. If a solar panel system is installed, additional types of electricity meters are brought together.

Bi-directional meters

Three display screens are available on bi-directional meters. The first is a test screen with all lights turned on. The second diagram depicts power coming in from the grid, while the third diagram depicts power leaving your solar system and entering the grid.

Normally, the screen notation 001 denotes power coming in and 002 denotes power leaving. DEL or DL, as well as REC or RC, are used on other meters to indicate which way the electricity is flowing.

Net-Meter

Net-Metering is a billing system that allows plant operators to feed excess electricity back into the grid and credits solar PV system owners for what they add to the grid.

This Electronic Meters for solar power systems help the plant operator who will need a digital meter called Net-Meter, which can accommodate electricity generated at its solar plant in both directions.

Consumption Meter

The consumption meter will show you how much electricity you’ve used, also including electricity generated by your solar system as well as electricity obtained from the utility company. Regardless, of the size of your building, this is almost always a CT meter.

Many inverter manufacturers are starting to include consumption monitoring in their inverters, giving solar system owners a better understanding of how much electricity they are using.

Feed-in meter

In the case of a feed-in tariff model; a Feed-in meter is require to determine how many kilowatts of solar power are fed into the utility grid.

The grid system operator frequently owns the feed-in meter. It receives a portion of the payment from the PV plant operator. Therefore, who can also purchase the Feed-in meter. A built-in backstop should include in the feed-in meter.

PV meter

The amount of electricity generate; by your solar system is measure with a PV meter. Accordingly, you won’t be transferring power to your solar system; this is a one-way meter.

Undoubtely, This is also for tax reasons, as one must pay sales tax on the amount of solar power consumed by oneself. The PV meter is the plant operator’s property at all times.

Conclusion

Installing an electric solar meter with your solar panel is a smart choice and move. Not only It overwhelms you its so many benefits but also, safe ground you use electricity too. In our opinion don’t go solar with a good solar meter. Get in touch with solar power systems installation company,  and get your solar meter today!
